I-STF-VIS 500-650

I-Orientalfiber STF-VIS 500-650 Hollow-Core Optical Fiber ifaka ukulahleka kokudlulisela okuphansi okungaphansi kuka-0.1 dB/m ku-spectrum yokukhanya okubonakalayo, iqinisekisa ukudluliswa kwe-optical okuzinzile nokusebenza kahle kwamandla aphezulu. Njengomkhiqizi ochwepheshe we-hollow-core optical fibre kanye nomphakeli e-China, i-Orientalfiber inikeza izixazululo ezinokwethenjelwa zefayibha zamalaser egesi, ukudluliswa kwe-pulse enamandla amakhulu, inzwa ye-biochemical, isizukulwane sokukhanya kwe-ultraviolet, ucwaningo lwesayensi kanye nezicelo ze-laser yezimboni nge-OEM nokusekelwa okuthe xaxa.

Thumela Uphenyo

Incazelo Yomkhiqizo

I-Orientalfiber STF-VIS 500-650 i-hollow-core optical fiber iletha ukuncishiswa okuphansi kakhulu ngaphansi kuka-0.1 dB/m kububanzi obubonakalayo be-waveth obungu-500-650 nm. Idizayinelwe ukudluliswa okungu-600 nm, le fibre engenalutho isekela ukulethwa kwe-pulse enamandla amakhulu, amasistimu e-laser yegesi, ukukhiqizwa kokukhanya kwe-UV, inzwa ye-biochemical, kanye nezinhlelo zokusebenza ze-spectroscopy. Umkhiqizi we-fiber optical optical ngokwezifiso ongenalutho kanye nomhlinzeki wezixazululo zezithombe ezinembayo.

Imininingwane

Into	Ukucaciswa
Uhlobo lweFiber	I-STF-VIS 500-650
Kulungiselelwe	600 nm
Okubalulekile	Umnyombo womoya
Idayamitha eyinhloko	28±2 μm
Uhlobo lwe-coating	Ijazi elibili elinenkomba ephezulu ye-acrylate
Ukunciphisa	<100 dB/km @ 600 nm
Umkhawulokudonsa wokudlulisa	500-650 nm
Imodi yenkambu yobubanzi	19.6±2 μm
Ukuhlakazeka	<2 ps/(nm·km) @ 600 nm
Ukuvuleka kwezinombolo	0.02
Ukucindezelwa kwe-HOM	>30 dB

Hot Tags: I-STF-VIS 500-650
