I-MPO Multi-fiber Push-on Cable ye-Fiber Optic (MPO≤24F)

I-MPO Multi-fiber Push-on Cable Cable (MPO≤24F) isebenzisa imicu eminingi enemibala enemibala efana ne-Optical Defert Media, embozwe ungqimba lwe-polyvinyl chloride (i-LSzH, ishefu eliphansi le-zero-halogen (i-flame-retardant) Sheath.

Thumela Uphenyo

Incazelo Yomkhiqizo

Izici

Usebenzisa imibala ye-Optical Fiber enemibala, ukuhlanganiswa okuphezulu

I-Aramid Yam njengelungu elinamandla okwenza ikhebula libe nokusebenza okuhle kakhulu kwamandla

Izinto zangaphandle zivimbela ukuthuthumela, zingavimbi manzi, i-uv-retardant, ilangabi - i-retardant kanye nemvelo enobungane bemvelo.

Izinja

Ngaphakathi noma yikuphi ukusatshalaliswa kwe-inhloso ye-inhloso

Intambo yesikhungo sedatha

Amazinga

Hlangana namazinga we-yd / t 1258.4, ICA-596, GR-4096, IEC 607944-20 / 21; Imikhiqizo ye-PVC iqinisekisiwe ngu-Ul, we-OFR ne-Ofnc; Imikhiqizo ye-LSZH Sebenzisa izinto ezahlukahlukene ukuze uhlangane neEC60332-1 noma i-IEC60332-3C.

Ukwakheka umdwebo

1. I-fiber

2. I-Aramid Yam

3. Ijacket

MPO Multi-fiber Push-on Fiber Optic Cable (MPO≤24f)

Amapharamitha Ezobuchwepheshe

Imodeli yekhebula	Ububanzi bekhebula (ref) (mm)	Isisindo sekhebula (Ref) (kg / km)		Amandla asheshayo Isikhathi eside / esifushane (N)	Ukugoba Radius Dynamic / Static (mm)
Imodeli yekhebula	Ububanzi bekhebula (ref) (mm)	Ijekethi ye-PVC	Ijekethi ye-lszh	Amandla asheshayo Isikhathi eside / esifushane (N)	Ukugoba Radius Dynamic / Static (mm)
12	3.0 ± 0.2	4.8	6.3	30/100	20D / 10D
24	3.6 ± 0.2	6.5	8.0	50/150	20D / 10D

Izici zokubona

Uhlobo lwefayibha	I-attenuation				Kabanzi	Imodi ye-bandwidth ephumelelayo	I-10 gbit / s ethernet	Umsakazo omncane wokugoba
Into efunekayo	1310 / 1550nm		850 / 1300nm		850 / 1300nm	I-850nm	I-850nm	/
Into efunekayo	Inani elijwayelekile	Inani eliphezulu	Inani elijwayelekile	Inani eliphezulu	850 / 1300nm	I-850nm	I-850nm	/
Umuvo	db / km	db / km	db / km	db / km	MHz.km	MHz.km	m	m
G657a1	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	10
G657a2	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	7.5
50/125	---	---	I-3.0 / 1.0	3.5 / 1.5	≥500 / 500	---	---	30
62.5 / 125	---	---	I-3.0 / 1.0	3.5 / 1.5	≥200 / 500	---	---	30
U-m3	---	---	I-3.0 / 1.0	3.5 / 1.5	≥1500 / 500	≥2000	≤300	30
U-m4	---	---	I-3.0 / 1.0	3.5 / 1.5	≥3500 / 500	≥4700	≤550	30

Ukuhamba / Isitoreji / Ukusebenza Kwezinga lokushisa: -20 ℃ - + 60 ℃, lokushisa lokufaka: -5 ℃ - + 50 ℃

MPO Multi-fiber Push-on Fiber Optic Cable (MPO≤24f)
