I-fiber ekhethekile yokusondela i-libsitivity ekhethekile inikezela nge-bandwidth ephezulu nempahla enhle yokuhambisa
Izintambo ezimbili ezihambisanayo noma izintambo zensimbi zenza ikhebula libe nokuphikiswa okuhle nokuvikela i-fiber optical
Uhlobo lomnsalo we-fiber optic drop cable unesakhiwo esilula nokusebenziseka okunamandla
Idizayini ye-Novel Flute, strip kalula kanye ne-splice, yenza lula ukufakwa nokulungisa
Intuthu ephansi, i-zero halogen ne-flame retardant sheath
1.lszh Jacket
Ilungu lamandla we-2.frfr
I-3.optical fiber unit
|
Imodeli yekhebula |
Ukubalwa kwefayibha |
Ubukhulu bekhebula (mm) |
Isisindo sekhebula (Ref) (kg / km) |
Amandla asheshayo Isikhathi eside / esifushane (N) |
Ukuchoboza ukumelana Isikhathi eside / esifushane (N / 100mm) |
Ukugoba Radius Dynamic / Static (mm) |
|
Gjxfh-1xn |
1 |
(2.0 ± 0.1) * (3.0 ± 0.1) |
8 |
40/80 |
500/1000 |
15/30 |
|
Gjxfh-2xn |
2 |
(2.0 ± 0.1) * (3.0 ± 0.1) |
8.5 |
40/80 |
500/1000 |
15/30 |
|
Gjxfjh-1xn |
1 |
(2.0 ± 0.1) * (3.8 ± 0.1) |
9 |
40/80 |
500/1000 |
15/30 |
|
Gxfdh-4xn |
4 (Ribbon) |
(2.0 ± 0.2) * (4.0 ± 0.2) |
10 |
40/80 |
500/1000 |
15/30 |
Ukugcina / Ukusebenza Kwezinga lokushisa: -20 ℃ ~ + 60 ℃
|
Uhlobo lwefayibha |
I-attenuation |
Kabanzi |
Imodi ye-bandwidth ephumelelayo |
I-10 gbit / s ethernet |
Umsakazo omncane wokugoba |
|||
|
Into efunekayo |
1310 / 1550nm |
850 / 1300nm |
850 / 1300nm |
I-850nm |
I-850nm |
/ |
||
|
Inani elijwayelekile |
Inani eliphezulu |
Inani elijwayelekile |
Inani eliphezulu |
|||||
|
Umuvo |
db / km |
db / km |
db / km |
db / km |
MHz.km |
MHz.km |
m |
m |
|
G657a1 |
0.36 / 0.22 |
0.5 / 0.4 |
--- |
--- |
--- |
--- |
--- |
10 |
|
G657a2 |
0.36 / 0.22 |
0.5 / 0.4 |
--- |
--- |
--- |
--- |
--- |
7.5 |
|
U-m3 |
--- |
--- |
I-3.0 / 1.0 |
3.5 / 1.5 |
≥1500 / 500 |
≥2000 |
≤300 |
30 |
|
U-m4 |
--- |
--- |
I-3.0 / 1.0 |
3.5 / 1.5 |
≥3500 / 500 |
≥4700 |
≤550 |
30 |
