Ikhebula le-Bow-Type Fiber Optic Drop Cable

Ikhebula le-Bow-Type Fiber Optic Drop Cable yakhelwe ukuxhumana okuthembekile okubonakalayo, ihlinzeka ngamandla aqinile okuqinile, ukuvimbela amanzi, kanye nokufaka kalula. Njengomkhiqizi nomphakeli owethembekile e-China, i-Orientalfiber iletha le Cable ye-Fiber Optic Drop ngqo kusuka efekthri yabasebenza ngocingo, amanethiwekhi edatha, noxhumo lwangaphambili lwezimboni. Iqinisekisa ukusebenza, ukuzinza, kanye nokusebenza kahle kwezindleko zamaphrojekthi ahlukahlukene.

Thumela Uphenyo

Incazelo Yomkhiqizo

Ikhebuli yethu yekhwalithi ephezulu yohlobo lwe-Bow Duct Fiber Optic Drop Cable yonke yenziwe eChina. I-Orientalfiber inguchwepheshe womkhiqizi we-Bow-Type Duct Fiber Optic Drop Cable kanye nomnikezeli e-China. Ungawathenga efektri yethu. Ukuze uthole ulwazi olwengeziwe, xhumana nathi manje.

Ikhebula le-Bow-Type Duct Fiber Optic Drop Cable iyikhebula elikhethekile lokubona ukufakwa kwepayipi, eliklanyelwe ukusekela ukuxhumana kwemayela lokugcina, okuhlanganisa i-Fiber To The Home (FTTH) noxhumo lwangaphambili lwemboni. Isakhiwo sayo esinamanzi kanye nomklamo owomile wokuvimbela amanzi kuvumela ukuhlubula okusheshayo nokuhlanganisa, kunciphisa isikhathi sokufaka nomzamo.

Izinzuzo Eziyinhloko

Isakhiwo esomile esinamanzi-ukuvimbela ukusebenza okuthembekile
Ukushuba okuphezulu nokumelana nokuchoboza kwezindawo ezifunayo
Idizayini etshibilikayo iqinisekisa ukukhumula okusheshayo nokunembayo kanye nokuhlanganisa
Ilula kodwa ihlala isikhathi eside, inciphisa umzamo wokubamba nokunakekela
Ukunikezwa okuqondile okuvela ku-Orientalfiber, umkhiqizi nomphakeli wase-China othembekile

Isicelos

Ikhebula lamapayipi angaphakathi nangaphandle
I-Fiber To The Home (FTTH) amanethiwekhi
Izixazululo zasembonini ezinqanyulwe ngaphambilini
Izixhumanisi zangaphambili zezimboni ngamandla, ezokuthutha zikaloliwe, nemigwaqo emikhulu

Isakhiwo Nempahla

Cha.	Into	Okubalulekile
1	Umgodla wangaphakathi	I-PVC, LSZH
2	Ilungu lamandla	Intambo yensimbi, i-FRP, i-KFRP
3	I-Fiber	I-G.652D (B1.3), G.657A1 (B6a1), G.657A2 (B6a2) …
4	Ilungu elisekela amandla	Intambo yensimbi, FRP
5	Izinto ezivimba amanzi	Itheyiphu yokuvimbela amanzi
6	Umgodla wangaphandle	LSZH, PE
7	Umbala	Mnyama

Bow-type Duct Fiber Optic Drop Cable

Impahla yekhebula

Uhlobo lwekhebula	Ubukhulu		Amandla aqinile		Ukumelana nokuchoboza		Irediyasi egobayo
	Iyunithi	Ikhebula	Isikhati eside	Isikhathi esifushane	Isikhati eside	Isikhathi esifushane	I-Static	Amandla
	(mm)		(N)		(N/100mm)		—
GJYXFH03 – 1/2/4	2.0×3.0	6.2	300	600	1000	2200	10 ·D	20 ·D
GJYXH03 – 1/2/4	2.0×3.0	6.2	300	600	1000	2200	10 ·D	20 ·D

Amanothi: D = Ububanzi bekhebula.

Isici seFiber

Uhlobo lwefiber	Ukunciphisa (Ubukhulu)		Ukulahlekelwa kwe-Macro bend ( Max)
	1310nm	1550nm	Φ30 mm Imibuthano engu-10(amajika)	Φ20mm Imibuthano engu-1(jika)	Φ15mm Imibuthano engu-1(jika)	Φ32 mm Imibuthano engu-1(jika)	Φ60 mm Imibuthano engu-100 (ukujika)
	(dB/km)		(dB)
G.652 D	0.40	0.30	N/a	N/a	N/a	0.05 @1550nm	0.05 @1625nm
G.657 A1	0.40	0.30	0.25 @1550nm 1.00 @1625nm	0.75 @1550nm 1.50 @1625nm	N/a	N/a	N/a
G.657 A2	0.40	0.30	0.03 @1550nm 0.10 @1625nm	0.1 @1550nm 0.2 @1625nm	0.5 @1550nm 1.0 @1625nm	N/a	N/a
