Ikhebula le-Simplex fib fiber optic

I-Simplex fib fiber cable cable isebenzisa i-Ople φ900μm noma i-Optical Buffered-buffered-buffered expression ephakathi, futhi ikhishwe ngongqimba we-polyvinyl chloride (i-LSzH, i-halogen-free, i-halogen-retardant) Sheath.

Thumela Uphenyo

Incazelo Yomkhiqizo

Izici

Fiff fuffer fiber kulula ukugqabhuka

I-Fight Buffer Fiber inokusebenza okuhle kwe-flame-retardant

I-Aramid Yarn Njengelungu Lezamandla lenza i-Simplex fiber optic ikhebula libe namandla amahle kakhulu

Izinto zejazi zangaphandle zinezinzuzo eziningi ezinjengokulwa nokugqwala, amanzi anti-amanzi, imisebe ye-antiolet, ilangabi - imbuyiselo engenabungozi emvelweni njll.

Izinja

Ukwenza izintambo ze-patch noma izingulube

Ukusatshalaliswa ngaphakathi

Xhumanisa phakathi kwamathuluzi, izinsiza zokuxhumana

Amazinga

Hlangana namazinga we-yd / t 1258.2, i-ICA-596, i-GR-4096, i-IEC 607944-2-10 / 11, njll. Ngaphezu kwemikhiqizo esedlule izitifiketi ze-ULOFNR kanye ne-Ofnp. Imikhiqizo ye-LSZH Sebenzisa izinto ezahlukahlukene ukuze uhlangane ne-IEC60332-1 noma i-IEC60332-3C noma isitifiketi se -NR.

Ukwakheka umdwebo

1.I-fiber buffer

I-2.aramid yarn

I-3.JackET

Simplex Fiber Optic Cable

Amapharamitha Ezobuchwepheshe

Imodeli yekhebula	Ububanzi bekhebula (ref) (mm)	Isisindo sekhebula (Ref) (kg / km)		Ububanzi be-TBF (μm)	Tensile Strenght Isikhathi eside / esifushane (N)	Ukuchoboza ukumelana Isikhathi eside / esifushane (N / 100mm)	Ukugoba Radius Dynamic / Static (mm)
Imodeli yekhebula	Ububanzi bekhebula (ref) (mm)	Ijekethi ye-PVC	Ijekethi ye-lszh	Ububanzi be-TBF (μm)	Tensile Strenght Isikhathi eside / esifushane (N)		Ukugoba Radius Dynamic / Static (mm)
1.6	1.6 ± 0.2	2.4	2.6	I-600 ± 50	40/80	100/500	60/30
1.9	1.9 ± 0.2	3.5	4.5	900 ± 50	60/100	100/500	60/30
2.8	2.8 ± 0.2	6.0	7.5	900 ± 50	60/100	100/500	60/30

Izici zokubona

Uhlobo lwefayibha	I-attenuation				Kabanzi	Imodi ye-bandwidth ephumelelayo	I-10 gbit / s ethernet	Umsakazo omncane wokugoba
Into efunekayo	1310 / 1550nm		850 / 1300nm		850 / 1300nm	I-850nm	I-850nm	/
Into efunekayo	Inani elijwayelekile	Inani eliphezulu	Inani elijwayelekile	Inani eliphezulu	850 / 1300nm	I-850nm	I-850nm	/
Umuvo	db / km	db / km	db / km	db / km	MHz.km	MHz.km	m	m
G652d	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	16
G657a1	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	10
G657a2	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	7.5
50/125	---	---	I-3.0 / 1.0	3.5 / 1.5	≥500 / 500	---	---	30
62.5 / 125	---	---	I-3.0 / 1.0	3.5 / 1.5	≥200 / 500	---	---	30
U-m3	---	---	I-3.0 / 1.0	3.5 / 1.5	≥1500 / 500	≥2000	≤300	30
U-m4	---	---	I-3.0 / 1.0	3.5 / 1.5	≥3500 / 500	≥4700	≤550	30

Simplex Fiber Optic Cable
