I-Duplex Flat Fig 8 Zipcord Fibc Fibtic Cable

I-Duplex Flat Fig 8 Zipcord FibCor Fibc Cable Usebenzisa i-Optical Fiber Or φ900μm sheath.

Thumela Uphenyo

Incazelo Yomkhiqizo

Izici

I-Fight Buffer fiber kalula yokuhlunga

I-Fight Buffer Fiber inokusebenza okuhle kwe-flame-retardant

Into eqinisiwe ye-ARAMID inika ikhebula amandla amahle kakhulu

I-Sheath Emiswe ngu-8 kulula ukuyisebenzisa futhi isebenzise amagatsha

Izinto zangaphandle zivimbela ukuthuthumela, zingavimbi manzi, i-uv-retardant, ilangabi - i-retardant kanye nemvelo enobungane bemvelo.

Izinja

I-Duplex Optical fiber patchcord noma ingulube

Ukusatshalaliswa ngaphakathi

Xhumanisa phakathi kwamathuluzi, imishini yokuxhumana

Amazinga

Hlangana namazinga we-yd / t 1258.2, i-ICA-596, i-GR-4096, i-IEC 607944-2-10 / 11, njll. Ngaphezu kwemikhiqizo esedlule izitifiketi ze-ULOFNR kanye ne-Ofnp. Imikhiqizo ye-LSZH isebenzisa izinto ezahlukene ukuze uhlangane ne-IEC60332-1 noma i-IEC60332-3c noma izitifiketi ze -NR noma ze-OFNR NO.

Ukwakheka umdwebo

1.I-fiber buffer

2.Aramid yarn jacket

I-3.JackET

Duplex Flat Fig 8 Zipcord Fiber Optic Cable

Amapharamitha Ezobuchwepheshe

Imodeli yekhebula	Ububanzi bekhebula (ref) (Mm)	Isisindo sekhebula (Ref) e o o o o		Ububanzi be-TBF (Μm)	Amandla asheshayo Isikhathi eside / esifushane (N)	Ukuchoboza ukumelana Isikhathi eside / esifushane (N / 100mm)	Ukugoba Radius Dynamic / Static (mm)
Imodeli yekhebula	Ububanzi bekhebula (ref) (Mm)	Ijekethi ye-PVC	Ijekethi ye-lszh	Ububanzi be-TBF (Μm)	Amandla asheshayo Isikhathi eside / esifushane (N)		Ukugoba Radius Dynamic / Static (mm)
1.6	(3.4 ± 0,3) × (1.6 ± 0.3)	4.8	5.3	I-600 ± 50	40/80	100/500	60/30
1.9	(4.0 ± 0.3) × (1.9 ± 0.3)	8.0	8.7	900 ± 50	100/200	100/500	60/30
2.8	(5.8 ± 0.3) × (2.8 ± 0.3)	11.6	14.8	900 ± 50	100/200	100/500	60/30

Izici zokubona

Uhlobo lwefayibha	I-attenuation				Kabanzi	Imodi ye-bandwidth ephumelelayo	I-10 gbit / s ethernet	Umsakazo omncane wokugoba
Into efunekayo	1310 / 1550nm		850 / 1300nm		850 / 1300nm	I-850nm	I-850nm	/
Into efunekayo	Inani elijwayelekile	Inani eliphezulu	Inani elijwayelekile	Inani eliphezulu	850 / 1300nm	I-850nm	I-850nm	/
Umuvo	db / km	db / km	db / km	db / km	MHz.km	MHz.km	m	m
G652d	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	16
G657a1	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	10
G657a2	0.36 / 0.22	0.5 / 0.4	---	---	---	---	---	7.5
50/125	---	---	I-3.0 / 1.0	3.5 / 1.5	≥500 / 500	---	---	30
62.5 / 125	---	---	I-3.0 / 1.0	3.5 / 1.5	≥200 / 500	---	---	30
U-m3	---	---	I-3.0 / 1.0	3.5 / 1.5	≥1500 / 500	≥2000	≤300	30
U-m4	---	---	I-3.0 / 1.0	3.5 / 1.5	≥3500 / 500	≥4700	≤550	30

Ukuhamba / Isitoreji / Ukusebenza Kwezinga lokushisa: -20 ℃ - + 60 ℃, lokushisa lokufaka: -5 ℃ - + 50 ℃

Duplex Flat Fig 8 Zipcord Fiber Optic Cable
