Invisible Bow-type Drop Fiber Optic Cable

I-Invisible Bow-type Drop Fiber Optic Cable iyikhebula elikhethekile lokudlulisa amehlo eliklanyelwe amanethiwekhi okufinyelela amabanga amafushane, alungele ikakhulukazi izimo ezidinga ukufakwa okungabonakali. Umkhiqizo wenziwa ngokubeka umkhono oqinile ongabonakali phakathi nendawo, ubeke izakhi ezimbili zokuqinisa ezihambisanayo ezinhlangothini zombili, futhi ekugcineni ukhiphe ungqimba lweshethi. Idizayini yayo ye-bow-section cross-section ayigcini nje ngokuthuthukisa ukuzinza kwesakhiwo kodwa futhi iqinisekisa ukungabonakali kwekhebula endaweni yasendlini, igwema umthelela ekuhlobiseni kwangaphakathi. I-Invisible Bow-Type Drop Fiber Optic Cable iyingxenye ebalulekile yomugqa womkhiqizo we-Orientalfiber, eklanyelwe ukuhlangabezana nesidingo esikhulayo sokudluliswa kobuhle nokusebenziseka kokubona ku-FTTH namaphrojekthi wekhebula angaphakathi.

Inani Eliyinhloko Lomkhiqizo

I-Invisible Bow-Type Drop Fiber Optic Cable igxile ekuxazululeni izindawo ezibuhlungu zezintambo eziconsisayo ezivamile ezifana nokufakwa okugqamile, ukukhumula okunzima nokungahambisani kahle nomhlobiso wangaphakathi. Ihlanganisa ukulula kwesakhiwo, isisindo esilula nokungabonakali, ihlinzeka ngesisombululo esilinganiselwe sokudluliselwa kwesignali nokuvumelana nemvelo. Njengomkhiqizo obalulekile we-Orientalfiber, ithuthukiswe ngokuqhubekayo ngokusekelwe kumpendulo yemakethe kanye nokuthuthukiswa kobuchwepheshe, iqinisekisa ukuthi ingakwazi ukuzivumelanisa nezimo ezihlukahlukene eziyinkimbinkimbi yokufaka ngaphakathi endlini kuyilapho igcina ukusebenza kokudlulisela okuzinzile.

Izici Eziyinhloko

Izici Zesakhiwo

Isakhiwo esilula, isisindo esincane kanye nokusebenza okuphezulu, okulula ukuthuthwa nokufakwa endaweni, kunciphisa amandla omsebenzi.

Idizayini ye-bow-section cross-section enezici ezimbili ezihambisanayo zokuqinisa ezinhlangothini zombili zomkhono oqinile ongabonakali omaphakathi, okuthuthukisa ukusebenza okuqinile nokucindezelwayo komkhiqizo.

Idizayini yomtshingo yenza kube lula ukuhlubula nokuhlanganisa, kunciphisa ubunzima bokwakhiwa kwendawo kanye nokuthuthukisa ukusebenza kahle kokufakwa ngaphandle kwesidingo samathuluzi ayinkimbinkimbi.

Izici Zokusebenza

Engabonakali futhi ayinawo umthelela emhlobiso wangaphakathi, i-sheath esobala noma ebonakala kancane ingahlanganiswa nezindonga, uphahla kanye nezinye izindawo, igcine ubuqotho bendawo yasendlini.

Ukunqanda ukudluliswa okuphansi, ukusebenzisa i-optical fiber core yekhwalithi ephezulu, ukuqinisekisa ukudluliswa kwesignali okuzinzile kanye nokuhlangabezana nezidingo zokudluliswa kwedatha ngesivinini esikhulu.

Ukuguquguquka okuhle kwemvelo, ukumelana namazinga okushisa aphezulu naphansi, umswakama kanye nokugqwala, kulungele izindawo ezihlukahlukene zasendlini njengezindawo zokuhlala, amahhovisi nezakhiwo zezentengiselwano.

Izici zokufaka

Kulula ukuyifaka, ingabekwa ngokuqondile eduze kwezindonga, amakhona noma ngamapayipi, ngaphandle kwemishini yokwakha emikhulu.

Ukunqanyulwa kwangaphambi kwesikhathi embonini kuyatholakala, okungagcina isikhathi sokuqedwa esizeni futhi kuqinisekise ukuvumelana kwekhwalithi yokuxhuma.

Izakhi zokuqinisa zithuthukisa amandla omshini womkhiqizo, zigwema ukulimala ngesikhathi sokufakwa nokusetshenziswa.

Isici

Isakhiwo esilula, isisindo esincane nokusebenza okuphezulu

Idizayini yomtshingo yenza kube lula ukuhlubula nokuhlanganisa

Okungabonakali futhi akunawo umthelela ekuhlobiseni kwangaphakathi

Isicelo

Ikhebula lasendlini

I-FTTH (I-Fiber Iya Ekhaya)

Kunqanyulwe ngaphambilini efekthri

Isakhiwo Nempahla

Impahla yekhebula

Isici seFiber

Ukusebenza Kwemvelo

Wonke amanani angenhla angenziwa ngendlela oyifisayo.

Imininingwane Yezobuchwepheshe

• Imininingwane ye-Optical

I-Invisible Bow-type Drop Fiber Optic Cable isebenzisa i-fiber optical fiber cores yemodi eyodwa noma yemodi eminingi, ithobela izindinganiso ze-ITU-T G.652, G.657A2 kanye ne-G.657B3. I-attenuation ku-1310nm ingu-≤0.36dB/km, futhi ukuncipha ku-1550nm kungu-≤0.22dB/km, okuqinisekisa ukudluliswa kwesignali yokulahlekelwa okuphansi. Indawo yokuvula izinombolo ingu-0.200±0.015 (imodi eyodwa) kanye no-0.275±0.015 (imodi eminingi), kanti ubude begagasi obunqamuliwe bekhebula bungu-≤1260nm, obuhambisana nemishini yokudlulisa amehlo evamile emakethe.

• Imininingwane Yemishini

Umkhiqizo unokusebenza okuhle kakhulu komshini, unamandla wesikhathi eside we-100N namandla wesikhashana we-200N. Ukumelana nengcindezi yesikhathi eside ye-lateral yi-≥1000N/100mm, futhi ukumelana nokucindezela kwesikhashana kwesikhashana kungu-≥2200N/100mm, okungamelana nokukhishwa nokudonsa ngesikhathi sokufakwa nokusebenzisa. Irediyasi yokugoba emile ingu-15D (D ububanzi bekhebula), futhi irediyasi yokugoba eguquguqukayo ingu-30D, elungele ukugotshwa nokulaliswa ezindaweni eziwumngcingo. Isisindo esivamile sekhebula ngu-7.9-9.9kg/km, elula futhi kulula ukuyiphatha.

• Imininingwane Yemvelo

Izinga lokushisa elisebenzayo le-Invisible Bow-type Drop Fiber Optic Cable lingu-40℃ ukuya ku-+85℃, futhi izinga lokushisa lokulondoloza lingu--40℃ ukuya ku-+85℃, elingakwazi ukuzivumelanisa nezimo ezicindezelayo zangaphakathi nezangaphandle. Impahla ye-sheath isebenzisa izinto ze-LSZH (Low Smoke Zero Halogen), ezingenabo ubuthi, ezingavimbeli ilangabi futhi zivumelane nemvelo, ezihlangabezana nezidingo zokuphepha zezindawo zomphakathi nezindawo zokuhlala. Iphinde ihambisane ne-RoHS, CE kanye nezinye izindinganiso zemvelo zamazwe ngamazwe.

• Imininingwane Engokwenyama

Ubukhulu bangaphandle bekhebula buyi-2.0 × 3.0mm (± 0.2mm), enesakhiwo esihlangene, esilungele ukubeka amapayipi amancane nezikhala. Ubukhulu be-sheath bungu-0.5-0.8mm, okuqinisekisa ukuvikelwa kwe-fiber optical yangaphakathi kanye nezici zokuqinisa. Izinto zokuqinisa zingakhethwa njengensimbi noma okungeyona insimbi (i-FRP) ngokuya ngezidingo zamakhasimende, ukuhlangabezana nezimo ezihlukene zokufakwa kanye nezidingo zokuphepha.

Izinhlelo zokusebenza

Izinkambu Zokusebenza Eziyinhloko

I-Invisible Bow yohlobo lwe-Drop Fiber Optic Cable isetshenziswa kakhulu ezimeni ezahlukene zokudlulisa amehlo amabanga amafushane, igxile ezinkambini zasendlini kanye ne-FTTH. Ukungabonakali kwayo nokufakwa kalula kwayo kuyenza ibe umkhiqizo okhethwayo wamaphrojekthi amaningi. Umkhiqizo usetshenziswa kakhulu kubaqhubi bemboni yezokuxhumana basekhaya nabangaphandle, umsakazo kanye nethelevishini ezinhlelweni zokuxhumana kanye nokudluliswa kolwazi, izinhlelo zokudlulisa idatha yenethiwekhi yendawo kanye noxhumo lwangaphambili lwezimboni ngamandla kagesi, ezokuthutha ngololiwe, imigwaqo emikhulu nezinye izimboni.

Izimo Zokusebenza Ezithize

I-FTTH (I-Fiber Iya Ekhaya)

Njengomthombo oyinhloko wokudlulisa wamaphrojekthi we-FTTH, Ikhebuli ye-Invisible Bow-Type Drop Fiber Optic Cable ixhuma ibhokisi lokusabalalisa elibonakalayo lomphakathi ekhaya lomsebenzisi, ibona ukufinyelela kwe-broadband ngesivinini esiphezulu. Idizayini yayo engabonakali igwema ukulimala komhlobiso wekhaya, futhi isici esilula sokuhlubula nokuhlanganisa sinciphisa ubunzima bokufakwa kwekhaya. Ifanele izindawo zokuhlala ezintsha, ukulungiswa komphakathi omdala namanye amaphrojekthi we-FTTH, ihlinzeka ngosekelo oluzinzile lwevidiyo engu-4K/8K, isipiliyoni se-VR nezinhlelo zokusebenza zasekhaya ezihlakaniphile.

I-Indoor Cabling

Ezakhiweni zamahhovisi, ezikhungweni zezentengiselwano, izibhedlela, izikole nezinye izindawo zasendlini, i-Invisible Bow-type Drop Fiber Optic Cable isetshenziselwa ukuxhunywa kwekhebula evundlile kanye nokuxhunywa kwemishini. Ingabekwa eduze kwezindonga, ophahleni noma ngamapayipi afihliwe, igcine ukuhlanzeka nobuhle bendawo yasendlini. Umkhiqizo ulungele ukudluliswa kwedatha yenethiwekhi yendawo, ibona ukuxhumana okunesivinini esikhulu phakathi kwaphansi nezinto zokusebenza, nokusekela izingqungquthela zevidiyo, ukuvumelanisa idatha enkulu namanye amabhizinisi ahamba phambili.

Izinhlelo zokusebenza zasefekthri ezinqanyulwe ngaphambilini

I-Invisible Bow-type Drop Fiber Optic Cable inganqanyulwa kuqala efektri ngokwezidingo zamakhasimende, kuncishiswe isikhathi sokwakha endaweni kanye nokwenza ngcono ukuqhubeka kwephrojekthi. Isetshenziswa kabanzi kumaphrojekthi amakhulu we-FTTH, izikhungo zedatha nezinye izimo ezidinga ukufakwa okusebenzayo, ukuqinisekisa ukuvumelana nokuthembeka kwekhwalithi yokuxhuma.

Izimo Ezikhethekile

Kwezinye izimo ezinezidingo eziphezulu zobuhle bemvelo, njengezindawo zokuhlala ezisezingeni eliphezulu, amagalari obuciko namahhotela kanokusho, Ikhebula le-Invisible Bow-Type Drop Fiber Optic Cable lingahlangana nendawo ezungezile, ligweme umthelela wezintambo zendabuko kusitayela sisonke. Ngesikhathi esifanayo, inguqulo yayo engeyona eyensimbi yokuqinisa ingasetshenziswa kuziteshi zamandla, izinkambu zikawoyela kanye nezinye izimo ezizwelayo ekuphazamiseni kazibuthe kagesi, okuqinisekisa ukudluliswa kwesignali okuzinzile.
